StarK Series

On-Line “Double Conversion” Technology,
DSP Controlled IGBT Rectifier UPS
3 phase in / 3phase out 10 to 40kVA

- IGBT Rectifier
- Real Digital Signal Processor (DSP) controlled transformerless design
- High Output Power Factor ( p.f.: 0,9 )
- Input Power Factor Correction PFC( >0,99 )
- Low Input Total Harmonic Distortion Level ( THDi ≤ 3% )
- High Efficiency ( up to 93% )
- Wide Input Voltage Range
- Cold Start Availability
- Increased Efficiency with Eco Mode Operation
- Fan Speed Control depending on internal temperature and load %
- Parallel Redundant Operation up to 4 Units
- Common Battery Application availability at Parallel Systems
- Configurable Battery Qty
- 16, 18 or 20pcs @ 10 to 30kVA / 32, 34, 36 or 40pcs @ 40kVA )
- 3 Step Intelligent battery charging system
- Static and Manual Bypass Built-in
- User Friendly LCD/LED Display Panel with functional keypads
- Remaining back up time indication on the LCD Display panel
- Power derating operation availability at high temperature and altitude
- EPO (Emergency Power Off) Function
- Short Circuit, Overload, Overtemperature, Deep Discharge protections
- USB, RS232, RS485 & Dry Contact Communication Ports
- Compact dimension with internal battery placement availability
